Description
Gen2 Ball-Bearing Turbo
9-blade billet 58/76mm compressor and dual ceramic ball bearings deliver up to 750 hp of fast-spooling boost.
750FWHP rated
65 lb/minMax air flow
58/76mmCompressor wheel
60/55mmTurbine wheel
Overview
The Pulsar PSR3076 Gen2 is a dual ceramic ball bearing performance turbocharger built around a 9-blade Gen2 billet compressor wheel (58mm inducer / 76mm exducer) with extended tapered-tip technology and an Inconel 713C 10-blade turbine wheel (60/55mm), flowing up to ~65 lb/min for a rated ~750 FWHP.
Aimed at high-horsepower street and track builds that want GTX3076R-class airflow and quick ball-bearing spool at a keener price, with a wide range of turbine housing A/R and flange options to suit different manifolds and applications.
Specifications
Compressor wheel9-blade Gen2 billet, 58mm inducer / 76mm exducer, extended tapered tip
Turbine wheelInconel 713C, 10-blade, 60/55mm
BearingDual ceramic ball bearing system
Turbine housing A/ROptions incl. T3 0.63/0.82/1.06, T4 0.85 divided, dual V-band 0.83/1.01 (confirm chosen option)
Rated power~750 FWHP, up to 65 lb/min max air flow
Turbine inlet flangeT3, T4 or 2.5" V-band (confirm option ordered)
Compressor inlet / outlet4" hose inlet / 2" hose outlet
Oil / water fittings-4AN oil feed via restrictor, standard T3 oil drain, M14x1.5 water
Compressor housingStandard, T51R Mod, or bare super core (confirm)
Part numberconfirm (varies by turbine housing / flange configuration)
What's in the box
- Turbocharger assembly
- V-band flange/clamp kit(s) for the exhaust housing (actuator per IWG option
- confirm)
Fitment
ApplicationUniversal (confirm flange/A-R)
InstallTurbine housing flange (T3 / T4 / V-band) and A/R must be matched to your manifold and target power; custom oil feed/drain and water plumbing required.
confirm flange, A/R and manifold fitment for your application before ordering
Best suited for
High-HP builds
Fast spool
Track & drag
Not a bolt-on; requires a compatible manifold, downpipe, oil/water plumbing and professional tuning. Exact wheel/turbine and flange must be confirmed against the specific configuration supplied.
